Description
Note:
(1) Please use A4 size papers.
(2) The lab report should be submitted online individually.
(3) Use Proteus 8.10 for simulation before the lab session. In the Proteus library, you should be able to find all the components used in the schematics. The lab report must include both the simulation and measurement results.
1. [Voltage Regulator] Build the voltage regulator below in Proteus and on the breadboard.
- (a) [10%] ForVs =5V,R=10kΩandRL =∞, use a voltage meter toobtain the value of VL . Discussion: Whether the obtained VL is
reasonable, in comparison to the VZ in the 1N4728A datasheet?
- (b) [20%] For Vs =5+0.5sin(2π60∙time), R=10kΩ and RL =∞, display both Vs and VL on oscilloscope. Estimate the line regulation by comparing the amplitudes of Vs and VL. By using the equation:line regulation = RZ⁄(R + RZ), estimate the value of RZ. Discussion:
If Vs = 2 + 3sin(2π60 ∙ time), how will VL change?
- (c) [20%] For Vs = 5 V and R = 10 kΩ, by gradually decreasing RL, find out the minimum R (RL,min), below which the voltage regulator stops working. Discussion: How to modify the voltage regulator so thatRL,min becomes 2 times smaller?
1
2. [Half-Wave Rectifier] Build the half-wave rectifier circuit below in Proteus and on the breadboard.
(a) [50%] For Vs = 5sin(2π60 ∙ time) and R = 1 kΩ, find out the value
of C so that the ripple voltage (Vr) is smaller than 0.1 V. Display Vout on oscilloscope to confirm Vr is indeed smaller than 0.1 V, and estimate Vdc, Idc, θc, ∆T, Ipeak, Isurge and PIV based on the waveforms. Make sure the half-wave rectifier is reliable, that is Ipeak, Isurge and PIV lower than the maximum ratings from the 1N4007 datasheet. Discussion: How will Vr change, if Vs = 5sin(2π120 ∙ time)?
2
1N4001, 1N4002, 1N4003, 1N4004, 1N4005, 1N4006, 1N4007
Axial-Lead Glass Passivated Standard Recovery Rectifiers
This data sheet provides information on subminiature size, axial lead mounted rectifiers for general−purpose low−power applications.
Features
• Shipped in Plastic Bags, 1000 per bag
• Available Tape and Reeled, 5000 per reel, by adding a “RL” suffix to
the part number
• Available in Fan−Fold Packaging, 3000 per box, by adding a “FF”
suffix to the part number
• Pb−Free Packages are Available
Mechanical Characteristics
• Case: Epoxy, Molded
• Weight: 0.4 gram (approximately)
• Finish: All External Surfaces Corrosion Resistant and Terminal
Leads are Readily Solderable
• Lead and Mounting Surface Temperature for Soldering Purposes:
260°C Max. for 10 Seconds, 1/16 in. from case • Polarity: Cathode Indicated by Polarity Band
*For additional information on our Pb−Free strategy and soldering details, please download the ON Semiconductor Soldering and Mounting Techniques Reference Manual, SOLDERRM/D.
www.onsemi.com
LEAD MOUNTED RECTIFIERS 50−1000 VOLTS DIFFUSED JUNCTION
CASE 59−10 AXIAL LEAD PLASTIC
MARKING DIAGRAM
A 1N400x YYWWG G
A = Assembly Location 1N400x = Device Number
x = 1, 2, 3, 4, 5, 6 or 7 YY = Year
WW = Work Week
G = Pb−Free Package
(Note: Microdot may be in either location)
ORDERING INFORMATION
See detailed ordering and shipping information on page 5 of this data sheet.
Publication Order Number:
1N4001/D
MAXIMUM RATINGS Rating
†Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage
†Non−Repetitive Peak Reverse Voltage (halfwave, single phase, 60 Hz)
†RMS Reverse Voltage
†Average Rectified Forward Current (single phase, resistive load,
60 Hz, TA = 75°C)
†Non−Repetitive Peak Surge Current (surge applied at rated load conditions)
Operating and Storage Junction Temperature Range
Symbol 1N4001 1N4002 1N4003 1N4004 1N4005 1N4006 1N4007 Unit
1N4001, 1N4002, 1N4003, 1N4004, 1N4005, 1N4006, 1N4007
VRRM VRWM VR
VRSM
VR(RMS) IO
IFSM
TJ Tstg
50
60 35
100
120 70
200
240 140
400 600
480 720
280 420 1.0
30 (for 1 cycle) −65 to +175
800 1000 V
1000 1200 V
560 700 V A
A °C
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.
†Indicates JEDEC Registered Data
THERMAL CHARACTERISTICS
Maximum Thermal Resistance, Junction−to−Ambient ELECTRICAL CHARACTERISTICS†
Rating
Maximum Instantaneous Forward Voltage Drop, (iF = 1.0 Amp, TJ = 25°C)
Maximum Full−Cycle Average Forward Voltage Drop, (IO = 1.0 Amp, TL = 75°C, 1 inch leads) VF(AV)
Maximum Reverse Current (rated DC voltage) IR
Rating
Symbol Max Unit
RqJA Note 1 °C/W
Symbol Typ Max Unit
vF 0.93 1.1 V − 0.8 V
(TJ = 25°C) (TJ = 100°C)
Maximum Full−Cycle Average Reverse Current, (IO = 1.0 Amp, TL = 75°C, 1 inch leads)
IR(AV)
mA 0.05 10
1.0 50
− 30 mA
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product performance may not be indicated by the Electrical Characteristics if operated under different conditions.
†Indicates JEDEC Registered Data
www.onsemi.com
2
10
1
0.1 0.5
0.8
VF, INSTANTANEOUS FORWARD VOLTAGE (V)
Figure 1. Typical Forward Voltage
100
10
1
1.2
1.0E−04 1.0E−05 1.0E−06 1.0E−07 1.0E−08 1.0E−09
1N4001, 1N4002, 1N4003, 1N4004, 1N4005, 1N4006, 1N4007
TC = 150°C
TC = 100°C
TC = 25°C
|
TC = 150°C |
|||||||||
|
TC = |
100°C |
||||||||
|
TC = |
25°C |
||||||||
0.6
0.7
0.9
1
1.1
0 100 200 300 400 500 600 700 800 9001000 VR, REVERSE VOLTAGE (V)
Figure 2. Typical Reverse Current
|
TJ = 25°C |
|||||||||||
0 20
80 100 120 140 160 180 200 VR, REVERSE VOLTAGE (V)
Figure 3. Typical Capacitance
40 60
www.onsemi.com
3
C, CAPACITANCE (pF)
IF, FORWARD CURRENT (A)
IR, REVERSE CURRENT (A)
1N4001, 1N4002, 1N4003, 1N4004, 1N4005, 1N4006, 1N4007
NOTE 1. − AMBIENT MOUNTING DATA
Data shown for thermal resistance, junction−to−ambient (RqJA) for the mountings shown is to be used as typical guideline values for preliminary engineering or in case the tie point temperature cannot be measured.
TYPICAL VALUES FOR RqJA IN STILL AIR
MOUNTING METHOD 1 LL
MOUNTING METHOD 2
LL
Vector Pin Mounting
MOUNTING METHOD 3 L = 3/8′′
Board Ground Plane
P.C. Board with
1−1/2′′ X 1−1/2′′ Copper Surface
|
Mounting Method |
Lead Length, L |
Units |
|||
|
1/8 |
1/4 |
1/2 |
|||
|
1 |
RqJA |
52 |
65 |
72 |
°C/W |
|
2 |
67 |
80 |
87 |
°C/W |
|
|
3 |
50 |
°C/W |
|||
www.onsemi.com
4
ÉÉÉÉÉÉÉÉÉÉÉÉ ÉÉÉÉÉÉÉÉÉÉÉÉ
ÉÉÉÉÉÉÉÉÉÉÉ ÉÉÉÉÉÉÉÉÉÉÉ
ÉÉ ÉÉ ÉÉ ÉÉ ÉÉ ÉÉ ÉÉ
ORDERING INFORMATION Device
1N4001 1N4001G
1N4001FF 1N4001FFG
1N4001RL 1N4001RLG
1N4002 1N4002G
1N4002FF 1N4002FFG
1N4002RL 1N4002RLG
1N4003 1N4003G
1N4003FF 1N4003FFG
1N4003RL 1N4003RLG
1N4004 1N4004G
1N4004FF 1N4004FFG
1N4004RL 1N4004RLG
1N4005 1N4005G
1N4005FF 1N4005FFG
1N4005RL 1N4005RLG
Package
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Shipping† 1000 Units/Bag 1000 Units/Bag
3000 Units/Box 3000 Units/Box
5000/Tape & Reel 5000/Tape & Reel
1000 Units/Bag 1000 Units/Bag
3000 Units/Box 3000 Units/Box
5000/Tape & Reel 5000/Tape & Reel
1000 Units/Bag 1000 Units/Bag
3000 Units/Box 3000 Units/Box
5000/Tape & Reel 5000/Tape & Reel
1000 Units/Bag 1000 Units/Bag
3000 Units/Box 3000 Units/Box
5000/Tape & Reel 5000/Tape & Reel
1000 Units/Bag 1000 Units/Bag
3000 Units/Box 3000 Units/Box
5000/Tape & Reel 5000/Tape & Reel
1N4001, 1N4002, 1N4003, 1N4004, 1N4005, 1N4006, 1N4007
†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D.
*This package is inherently Pb−Free.
www.onsemi.com
5
ORDERING INFORMATION Device
1N4006 1N4006G
1N4006FF 1N4006FFG
1N4006RL 1N4006RLG
1N4007 1N4007G
1N4007FF 1N4007FFG
1N4007RL 1N4007RLG
Package
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Axial Lead*
Axial Lead* (Pb−Free)
Shipping† 1000 Units/Bag 1000 Units/Bag
3000 Units/Box 3000 Units/Box
5000/Tape & Reel 5000/Tape & Reel
1000 Units/Bag 1000 Units/Bag
3000 Units/Box 3000 Units/Box
5000/Tape & Reel 5000/Tape & Reel
1N4001, 1N4002, 1N4003, 1N4004, 1N4005, 1N4006, 1N4007
†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D.
*This package is inherently Pb−Free.
www.onsemi.com
6
MECHANICAL CASE OUTLINE
PACKAGE DIMENSIONS
AXIAL LEAD
CASE 59−10 ISSUE U
B
D
A
F K
DATE 15 FEB 2005
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI
STYLE 1
SCALE 1:1
STYLE 2
K
F
2. 3.
4. 5.
Y14.5M, 1982.
CONTROLLING DIMENSION: INCH.
ALL RULES AND NOTES ASSOCIATED WITH JEDEC DO−41 OUTLINE SHALL APPLY POLARITY DENOTED BY CATHODE BAND. LEAD DIAMETER NOT CONTROLLED WITHIN F DIMENSION.
INCHES
MILLIMETERS MIN MAX 4.10 5.20 2.00 2.70 0.71 0.86
−−− 1.27 25.40 −−−
POLARITY INDICATOR OPTIONAL AS NEEDED (SEE STYLES)
DIM A B D F K
MIN
0.161 0.079 0.028
−−− 1.000
MAX
0.205 0.106 0.034 0.050
−−−
GENERIC MARKING DIAGRAM*
AA xxx
xxx YYWW
STYLE 2
= Specific Device Code = Assembly Location
= Year
= Work Week
STYLE 1:
PIN 1. CATHODE (POLARITY BAND)
2. ANODE
STYLE 2:
xxx xxx YYWW
NO POLARITY
STYLE 1
xxx A YY WW
*This information is generic. Please refer to device data sheet for actual part marking. Pb−Free indicator, “G” or microdot “ G”, may or may not be present.
|
DOCUMENT NUMBER: |
Electronic versions are uncontrolled except when accessed directly from the Document Repository. 98ASB42045B Printed versions are uncontrolled except when stamped “CONTROLLED COPY” in red. |
|
DESCRIPTION: |
AXIAL LEAD PAGE 1 OF 1 |
ON Semiconductor and are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries. ON Semiconductor reserves the right to make changes without further notice to any products herein. ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. ON Semiconductor does not convey any license under its patent rights nor the rights of others.
© Semiconductor Components Industries, LLC, 2019
www.onsemi.com
ON Semiconductor and are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or other countries. ON Semiconductor owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of ON Semiconductor’s product/patent coverage may be accessed at www.onsemi.com/site/pdf/Patent−Marking.pdf. ON Semiconductor reserves the right to make changes without further notice to any products herein. ON Semiconductor makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ON Semiconductor assume any liability arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages. Buyer is responsible for its products and applications using ON Semiconductor products, including compliance with all laws, regulations and safety requirements or standards, regardless of any support or applications information provided by ON Semiconductor. “Typical” parameters which may be provided in ON Semiconductor data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. ON Semiconductor does not convey any license under its patent rights nor the rights of others. ON Semiconductor products are not designed, intended, or authorized for use as a critical component in life support systems or any FDA Class 3 medical devices or medical devices with a same or similar classification in a foreign jurisdiction or any devices intended for implantation in the human body. Should Buyer purchase or use ON Semiconductor products for any such unintended or unauthorized application, Buyer shall indemnify and hold ON Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that ON Semiconductor was negligent regarding the design or manufacture of the part. ON Semiconductor is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.
PUBLICATION ORDERING INFORMATION
LITERATURE FULFILLMENT:
Email Requests to: orderlit@onsemi.com
ON Semiconductor Website: www.onsemi.com ◊
TECHNICAL SUPPORT
North American Technical Support:
Voice Mail: 1 800−282−9855 Toll Free USA/Canada Phone: 011 421 33 790 2910
Europe, Middle East and Africa Technical Support:
Phone: 00421 33 790 2910
For additional information, please contact your local Sales Representative
www.onsemi.com
1
Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
ON Semiconductor:
1N4004 1N4005 1N4007 1N4001 1N4001FF 1N4001FFG 1N4001G 1N4001RL 1N4001RLG 1N4002
1N4002FF 1N4002FFG 1N4002G 1N4002RL 1N4002RLG 1N4003 1N4003FF 1N4003FFG 1N4003G 1N4003RL 1N4003RLG 1N4004FF 1N4004FFG 1N4004G 1N4004RL 1N4004RLG 1N4005FF 1N4005FFG 1N4005G
1N4005RL 1N4005RLG 1N4006 1N4006FF 1N4006FFG 1N4006G 1N4006RL 1N4006RLG 1N4007FF 1N4007FFG 1N4007G 1N4007RL 1N4007RLG
www.vishay.com
1N4728A to 1N4764A
Vishay Semiconductors
Zener Diodes
FEATURES
DESIGN SUPPORT TOOLS AVAILABLE
- Silicon planar power Zener diodes
- For use in stabilizing and clipping circuits with high power rating
- Standard Zener voltage tolerance is ± 5 %
- AEC-Q101 qualified
- Material categorization:
for definitions of compliance please see www.vishay.com/doc?99912APPLICATIONS• Voltage stabilization
3D Models
|
PRIMARY CHARACTERISTICS |
||
|
PARAMETER |
VALUE |
UNIT |
|
VZ range nom. |
3.3 to 100 |
V |
|
Test current IZT |
2.5 to 76 |
mA |
|
VZ specification |
Thermal equilibrium |
|
|
Circuit configuration |
Single |
|
|
ORDERING INFORMATION |
|||
|
DEVICE NAME |
ORDERING CODE |
TAPED UNITS PER REEL |
MINIMUM ORDER QUANTITY |
|
1N4728A to 1N4764A |
1N4728A to 1N4764A -series-TR |
5000 per 13″ reel |
25 000/box |
|
1N4728A to 1N4764A |
1N4728A to 1N4764A-series-TAP |
5000 per ammopack (52 mm tape) |
25 000/box |
|
PACKAGE |
||||
|
PACKAGE NAME |
WEIGHT |
MOLDING COMPOUND FLAMMABILITY RATING |
MOISTURE SENSITIVITY LEVEL |
SOLDERING CONDITIONS |
|
DO-41 (DO-204AL) |
310 mg |
UL 94 V-0 |
MSL level 1 (according J-STD-020) |
Peak temperature max. 260 °C |
|
ABSOLUTE MAXIMUM RATINGS (Tamb = 25 °C, unless otherwise specified) |
||||
|
PARAMETER |
TEST CONDITION |
SYMBOL |
VALUE |
UNIT |
|
Power dissipation |
Valid provided that leads at a distance of 4 mm from case are kept at ambient temperature |
Ptot |
1300 |
mW |
|
Zener current |
IZ |
PV/VZ |
mA |
|
|
Thermal resistance junction to ambient air |
Valid provided that leads at a distance of 4 mm from case are kept at ambient temperature |
RthJA |
110 |
K/W |
|
Junction temperature |
Tj |
175 |
°C |
|
|
Storage temperature range |
Tstg |
-65 to +175 |
°C |
|
|
Forward voltage (max.) |
IF = 200 mA |
VF |
1.2 |
V |
Rev. 2.5. 12-Mar-2019 1
For technical questions within your region: DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Document Number: 85816
D D
3 3
www.vishay.com
1N4728A to 1N4764A
Vishay Semiconductors
|
ELECTRICAL CHARACTERISTICS (Tamb = 25 °C, unless otherwise specified) |
|||||||||
|
PART NUMBER |
ZENER VOLTAGE RANGE (1) |
TEST CURRENT |
REVERSE LEAKAGE CURRENT |
DYNAMIC RESISTANCE f = 1 kHz |
SURGE CURRENT (3) |
REGULATOR CURRENT (2) |
|||
|
VZ at IZT1 |
IZT1 |
IZT2 |
IR at VR |
ZZT at IZT1 ZZK at IZT2 |
IR |
IZM |
|||
|
V |
mA |
mA |
μA |
V |
|
mA |
mA |
||
|
NOM. |
MAX. |
TYP. |
MAX. |
MAX. |
|||||
|
1N4728A |
3.3 |
76 |
1 |
100 |
1 |
10 |
400 |
1380 |
276 |
|
1N4729A |
3.6 |
69 |
1 |
100 |
1 |
10 |
400 |
1260 |
252 |
|
1N4730A |
3.9 |
64 |
1 |
50 |
1 |
9 |
400 |
1190 |
234 |
|
1N4731A |
4.3 |
58 |
1 |
10 |
1 |
9 |
400 |
1070 |
217 |
|
1N4732A |
4.7 |
53 |
1 |
10 |
1 |
8 |
500 |
970 |
193 |
|
1N4733A |
5.1 |
49 |
1 |
10 |
1 |
7 |
550 |
890 |
178 |
|
1N4734A |
5.6 |
45 |
1 |
10 |
2 |
5 |
600 |
810 |
162 |
|
1N4735A |
6.2 |
41 |
1 |
10 |
3 |
2 |
700 |
730 |
146 |
|
1N4736A |
6.8 |
37 |
1 |
10 |
4 |
3.5 |
700 |
660 |
133 |
|
1N4737A |
7.5 |
34 |
0.5 |
10 |
5 |
4 |
700 |
605 |
121 |
|
1N4738A |
8.2 |
31 |
0.5 |
10 |
6 |
4.5 |
700 |
550 |
110 |
|
1N4739A |
9.1 |
28 |
0.5 |
10 |
7 |
5 |
700 |
500 |
100 |
|
1N4740A |
10 |
25 |
0.25 |
10 |
7.6 |
7 |
700 |
454 |
91 |
|
1N4741A |
11 |
23 |
0.25 |
5 |
8.4 |
8 |
700 |
414 |
83 |
|
1N4742A |
12 |
21 |
0.25 |
5 |
9.1 |
9 |
700 |
380 |
76 |
|
1N4743A |
13 |
19 |
0.25 |
5 |
9.9 |
10 |
700 |
344 |
69 |
|
1N4744A |
15 |
17 |
0.25 |
5 |
11.4 |
14 |
700 |
304 |
61 |
|
1N4745A |
16 |
15.5 |
0.25 |
5 |
12.2 |
16 |
700 |
285 |
57 |
|
1N4746A |
18 |
14 |
0.25 |
5 |
13.7 |
20 |
750 |
250 |
50 |
|
1N4747A |
20 |
12.5 |
0.25 |
5 |
15.2 |
22 |
750 |
225 |
45 |
|
1N4748A |
22 |
11.5 |
0.25 |
5 |
16.7 |
23 |
750 |
205 |
41 |
|
1N4749A |
24 |
10.5 |
0.25 |
5 |
18.2 |
25 |
750 |
190 |
38 |
|
1N4750A |
27 |
9.5 |
0.25 |
5 |
20.6 |
35 |
750 |
170 |
34 |
|
1N4751A |
30 |
8.5 |
0.25 |
5 |
22.8 |
40 |
1000 |
150 |
30 |
|
1N4752A |
33 |
7.5 |
0.25 |
5 |
25.1 |
45 |
1000 |
135 |
27 |
|
1N4753A |
36 |
7 |
0.25 |
5 |
27.4 |
50 |
1000 |
125 |
25 |
|
1N4754A |
39 |
6.5 |
0.25 |
5 |
29.7 |
60 |
1000 |
115 |
23 |
|
1N4755A |
43 |
6 |
0.25 |
5 |
32.7 |
70 |
1500 |
110 |
22 |
|
1N4756A |
47 |
5.5 |
0.25 |
5 |
35.8 |
80 |
1500 |
95 |
19 |
|
1N4757A |
51 |
5 |
0.25 |
5 |
38.8 |
95 |
1500 |
90 |
18 |
|
1N4758A |
56 |
4.5 |
0.25 |
5 |
42.6 |
110 |
2000 |
80 |
16 |
|
1N4759A |
62 |
4 |
0.25 |
5 |
47.1 |
125 |
2000 |
70 |
14 |
|
1N4760A |
68 |
3.7 |
0.25 |
5 |
51.7 |
150 |
2000 |
65 |
13 |
|
1N4761A |
75 |
3.3 |
0.25 |
5 |
56 |
175 |
2000 |
60 |
12 |
|
1N4762A |
82 |
3 |
0.25 |
5 |
62.2 |
200 |
3000 |
55 |
11 |
|
1N4763A |
91 |
2.8 |
0.25 |
5 |
69.2 |
250 |
3000 |
50 |
10 |
|
1N4764A |
100 |
2.5 |
0.25 |
5 |
76 |
350 |
3000 |
45 |
9 |
Notes
(1) Based on DC measurement at thermal equilibrium while maintaining the lead temperature (TL) at 30 °C + 1 °C, 9.5 mm (3/8″) from the diode body
- (2) Valid provided that electrodes at a distance of 4 mm from case are kept at ambient temperature
- (3) tp = 10 ms.
Rev. 2.5. 12-Mar-2019 2 Document Number: 85816 For technical questions within your region: DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
1N4728A to 1N4764A
Vishay Semiconductors
BASIC CHARACTERISTICS (Tamb = 25 °C, unless otherwise specified)
1400 1200 1000
800 600 400 200
0
0 50 100 150 200
Tamb- Ambient Temperature (°C)
Fig. 1 – Admissible Power Dissipation vs. Ambient Temperature Ptot = f (Tamb)
PACKAGE DIMENSIONS in millimeters (inches): DO-41 (DO-204AL)_1N47xx
Cathode Identification
26 min. [1.024]
Document no. S8-V-3901.04-001(4)
Rev. 1 – Date: 30. Nov. 2011 22624
4.1 max. [0.161] 3.3 min. [0.128]
26 min. [1.024]
Rev. 2.5. 12-Mar-2019 3 Document Number: 85816 For technical questions within your region: DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Ø 0.86 max. [0.034] Ø 0.7 min. [0.027]
Ø 2.6 max. [0.102] Ø 2.1 min. [0.081]
Ptot – Power Dissipation (mW)
www.vishay.com
Legal Disclaimer Notice
Vishay
© 2019 VISHAY INTERTECHNOLOGY, INC. ALL RIGHTS RESERVED
Disclaimer
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other disclosure relating to any product.
Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special, consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular purpose, non-infringement and merchantability.
Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding statements about the suitability of products for a particular application. It is the customer’s responsibility to validate that a particular product with the properties described in the product specification is suitable for use in a particular application. Parameters provided in datasheets and / or specifications may vary in different applications and performance may vary over time. All operating parameters, including typical parameters, must be validated for each customer application by the customer’s technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein.
Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining applications or for any other application in which the failure of the Vishay product could result in personal injury or death. Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.
Revision: 01-Jan-2019 1 Document Number: 91000
